| Brand Name : | Hengyang |
| Model Number : | HC-399 |
| Certification : | ISO9001 |
| Price : | 5600-356100 |
| Payment Terms : | T/T |
| Supply Ability : | 270 sets/month |
| Delivery Time : | 15-20 days |
Jaw crusher is combined with the secondary crushing equipment in the whole stone crushing line,like cone crusher and impact crusher. Due to their smaller physical size, jaw crushers are also ideal for tight spaces, such as underground mining and mobile crushing applications.

Common parameters of jaw crusher
| Model | Opening size(mm) | Max feeding size(mm) | Output adjust range(mm) | Production capacity(t/h) | Power (kw) |
| PE250*400 | 250*400 | 200 | 20-50 | 5-20 | 15 |
| PE400*600 | 400*600 | 350 | 40-100 | 15-60 | 30-37 |
| PE500*700 | 500*700 | 425 | 50-100 | 40-110 | 45-55 |
| PE600*900 | 600*900 | 480 | 65-160 | 90-180 | 55-75 |
| PE750*1060 | 750*1060 | 630 | 80-140 | 110-320 | 90-110 |
| PE900*1200 | 900*1200 | 750 | 95-165 | 220-450 | 110-132 |
| PE1200*1500 | 1200*1500 | 1020 | 150-300 | 400-800 | 160-200 |

Working principle of stone jaw crusher motor drives the eccentric
axis rotating throughthe belt pulley, so that the movable jaw
approaches and leaves the fixed jaw cyclical,which makes the
materials squeezed. rubbed. multi-roller crusher, etc. so that
thematerials are crushed into small size, and then decline
gradually, at last dischargefrom the discharging mouth
|
